Eurolife EL-RS20/11 UPA120 Booster Pump (Green)
Brand: Eurolife Vietnam
Power: 120W – 250W
Maximum pump capacity: 60 liters/minute
Warranty: 1 year
The machine starts automatically when you turn on the tap or use water appliances.
Turn it off when you stop using the water supply.
This pump is specifically designed for hot water sources up to 100°C.°C, solar energy system.
Two threaded connections: 27mm
It’s a useful tool for households with weak water supply, insufficient for washing machines or showers…
Support for solar power systems when installed at tower level, low pressure.
The machine is compact, easy to install (connected horizontally to the water supply), consumes very little electricity, and is noiseless.
The machine starts automatically when a tap or similar device is opened and automatically turns off when the tap is closed.
Power:
Power consumption: 250W Power supply: 220V-50Hz
Pump capacity: 60 liters/minute. Maximum head: 12 meters
(Head pressure is tested under ideal conditions: straight pump line, strong water supply to the machine and
(No gravity compresses down on the thrust end of the machine)
Minimum level (1 dash): Pumping 30 liters/minute with a power of approximately 120W.
If you’re looking for a device to increase water pressure for your washing machine, shower, kitchen faucet, etc., then this machine is for you.
The Eurolife EL-RS 20/11 pump is an optimal choice.
The machine meets most of the criteria, such as:
Excellent boost performance, energy efficient, compact, easy to install and use, and noiseless…
If you need a pump with higher power and the same specifications, please refer to other models.
Other Eurolife pumps such as RS 25/8G
Extremely versatile for various pumping needs.
Two pumping modes:
1. The pump automatically activates when the water tap or other devices are in use. It automatically shuts off when the water supply is turned off.
2. Continuous forced pumping.
Operating environment: The pump can handle hot water up to 100 degrees Celsius.
Important note: This machine does not support water suction. It only operates when water flows through its body.
The casing is made of steel.
Ceramic shaft. 3/4” (D27) connectors at both ends. Body length 18cm.
Compact body with a diameter of 10cm.
Weight: 5500 grams
Noise level 35db (almost inaudible when the engine is running)
Installation :
1. Thoroughly flush the water supply pipes before installation. If the water flowing through the machine contains impurities, algae, or scale,
Install a debris filter before installing the machine.
2. Connect the water inlet and outlet according to the arrows engraved on the machine body. Installation method: Place the machine upright.
The relay and water flow direction should follow the arrow as shown on the machine body.
(See illustration)
Connect the relay’s connector to the socket on the power cord.
The power cord has a switch with 3 modes:
But Auto (The pump will automatically start pumping when water flows through it – when the tap is opened and water-using devices are connected.)
– Stop (Turn off the machine – it will not run even if water is flowing through it.)
– Manual (The machine will run whether or not there is water flowing through it – Note the function)
This will affect the product’s lifespan because the machine will run continuously only when someone is present.
(Use the manual pump shut-off feature)
(still intact)
to allow water to get into the parts.
Experience Eurolife brand products and feel the value we bring to our customers.
Quality, reliability, and excellent after-sales service are always our commitments.
Eurolife is a professional manufacturer and leading brand in the field of shower heads, bathroom fixtures, and accessories.
Kitchens in Vietnam.
*************************************** AWARD-WINNING PRODUCT **********************************************
– Gold medal and title for high-quality products meeting international standards (Awarded by the Union)
(certified by Vietnamese scientific associations)
– Top 500 leading products and services in Vietnam as voted by consumers.
Eurolife – Proudly a Vietnamese brand
Warranty: 1 year
